Description

Feature

  • Non-mydriatic and minimum puil size2.5mm
  • Low light LED flash and 480*800 HD touch screen
  • Auto focus and 8 target fixation
  • 8mega and 8 mega pixel lens option
  • image Auto-mosaic
  • Android system ,easier operation and data storage
  • reading ,wireless transfer
  • DICOM interface
  • 4G Networks
  • Intergrated design only 560g
  • No additional computer or mobile device will be required

Technical Data

Model HFC-900
FOV 45°
Minimum pupil 2.5mm
Refractive compensation -20D~+20D
Focus Way Auto/manual
Focus mode 8Targets fixation
Light source White LED/IR
Image resolution 16MP
Screen 3.97 INCH MULTI TARGETS TOUCH SCREEN 800*400
Shoot Type Infrared ,white light
Image format JPEG
Transmission and storage Internal capacity 8GB Support Micro SD (Max:128GB)USB/Wifi/BT/4G
Weight 560g
Power supply Lithium battery 3.7V 3400mAh
The battery continuously working time 33h (Standby time exceeds 24h)
Total chargint time 3.5-4h
Operationg system Win7/win8/win10/ios/android
ID Card reading and collection yes
NFC Card reader yes
Connect function Professional software , APP. Support Dicom,support cloud service system,Patient data management software , support wireless printing
G. Weight 2.5kg
Size 160mm*90mm*190mm
Packing size 360mm*310mm*160mm
